UPS OLS Tower 1000VA/900W

คุณสมบัติสินค้า:

GENERAL Phase Single Phase UPS Topology Online Double Conversion Energy Saving Technology Online ECO Mode Efficiency > 95% Active PFC Compatibility Yes INPUT Generator Compatibility Yes Nominal Input Voltage ( Vac ) 230 ± 10% Input Voltage Range ( Vac ) 160 ~ 300 Adjustable Voltage Range ( Vac ) 0~50% Load for 110 ~ 300 Vac 0~60% Load for 120 ~ 300 Vac 0~80% Load for 140 ~ 300 Vac 0~100% Load for 160 ~ 300 Vac Input Frequency ( Hz ) 50 ± 10 60 ± 10 Input Frequency Detection Auto-sensing Rated Input Current ( A ) 4.5 Input Power Factor 0.98 Input Connector Type IEC C14 Plug Style Right Angle Detachable Power Cord Plug Type IN/ZA x 1 Power Cord Length (ft.) 5.9 Power Cord Length (m.) 1.8 OUTPUT Capacity (VA) 1000 Capacity (Watts) 900 On Battery Waveform Pure Sine Wave On Battery Voltage(s) ( Vac ) 208 ± 1% 220 ± 1% 230 ± 1% 240 ± 1% Output Voltage Setting Configurable On Battery Frequency ( Hz ) 50 ± 0.5% 60 ± 0.5% Output Frequency Setting Configurable Power Factor 0.9 ECO Mode Voltage Tolerance ± 15 % Overload Protection Internal Current Limiting , Circuit Breaker , Fuse Overload Protection (Line Mode) 110~120% Load for 1 min, >120% Load Immediately Overload Protection (Battery Mode) 110~120% Load for 10 sec, >120% Load Immediately Overload Protection (Bypass Mode) >130% Load Immediately Crest Factor 3 : 1 Harmonic Distortion (Linear Load) THD<3% Harmonic Distortion (Non-linear Load) THD<5% Internal Bypass Automatic Bypass , Manual Bypass Outlet(s) – Total 4 Outlet Type IEC C13 x 4   Outlet(s) – Battery & Surge Protected 4 Typical Transfer Time ( ms ) 0 BATTERY Runtime at Half Load ( min ) 15 Runtime at Full Load ( min ) 5 Typical Recharge Time ( Hours ) 5 Maximum Charging Current ( A ) 1 Start On Battery Yes Smart Battery Management (SBM) Yes User-replaceable No Battery Type Sealed Lead-acid Battery Quantity (Each RBP) ( pcs ) 3 Battery Voltage (Each RBP) ( V ) 36 Single Battery Capacity ( AH ) 12 V 7 AH Extended Battery Module (EBM) BPSE36V45A Max. EBM Quantity ( pcs ) 3 SURGE PROTECTION & FILTERING Surge Suppression ( Joules ) 440 EMI/RFI Filtration Yes Phone/Network Protection RJ11/RJ45 (Combo) 1-in, 1-out Phone Protection RJ11 1-in, 1-out MANAGEMENT & COMMUNICATIONS LCD Panel Yes LCD Information Display Operation Type , Power Status , Battery Status , Load Status , Fault & Warning , Other Information , Event & Log LCD Setting & Control Mode Setting , Alarm Setting , Input & Output , Battery Setting , Fault & Warning HID Compliant USB Port(s) 1 Emergency Power Off (EPO) Port Yes Audible Alarms Battery Mode , Low Battery , Overload , Overcharge , Overheat , UPS Fault , Replace Battery Management Cable ( pcs ) Power Cord x2 , USB Cable x1 , Phone Line x1 Power Management Software PowerPanel® Business SNMP/HTTP Remote Monitoring Yes – with optional RMCARD205 PHYSICAL Form Factor Tower Enclosure Construction Metal Color Black PHYSICAL SIZE – UPS MODULE Dimensions (WxHxD) (in.) 5.94 x 8.86 x 15.51 Dimensions (WxHxD) (mm.) 151 x 225 x 394 Weight (lbs.) 28.88 Weight (kg.) 13.1 SHIPPING DIMENSIONS Dimensions (WxHxD) (in.) 9.5 x 12.32 x 20.08 Dimensions (WxHxD) (mm.) 241 x 313 x 510 Weight (lbs.) 32.19 Weight (kg.) 14.6 ENVIRONMENTAL Operating Temperature (°F) 32 ~ 104 Operating Temperature (°C) 0 ~ 40 Operating Relative Humidity (Non-condensing) ( % ) 20 ~ 90 Operating Elevation ( feet/meters ) 0-5,000 feet (0-1,500 meters) Storage Temperature (°F) -4 ~ 122 Storage Temperature (°C) -20 ~ 50 Storage Relative Humidity (Non-condensing) ( % ) 10 ~ 90 Storage Elevation ( feet/meters ) 0-5,000 feet (0-1,500 meters) Online Thermal Dissipation ( BTU/hr ) 342 Audible Noise at 1.5M from Surface of Unit ( dBA ) 45 CERTIFICATIONS Certifications CE , BIS , EAC , LOA RoHS Yes RELATED PRODUCTS

หมวดหมู่ : POWER SYSTEM UPS

แบรนด์ : CYBER POWER
